UNIT TA-1044
AVAILABLE NOW
IN THE BAY 34 DAYS · CLEAN · GEORGIA, IN HAND
2016 Chevrolet Silverado 1500 LTZ Crew Cab 4x4
Photograph: Bull-Doser · Public domain · source
Victory Red over Jet black leather · truck · stock TA-1044
ASKING PRICE
$24,900
VS MARKET
-4%
Mileage
96,150 mi
Condition
85 /100
Power
355 hp
0–60 mph
6.9 s
Measurement sheet
Every reading on one page.
The sheet travels with the car: 120 measured points, the dyno figures, the condition scores and the defect log. Ask for the PDF and you get exactly this, plus the photographs taken in the bay.
MEASURED
Condition by system
7 SYSTEMS
Scores are the weighted result of the 120-point protocol for each system, not an opinion. Red under 82, amber to 90, cyan above.
INSTRUMENTS
Key readouts
BAY LOG
Torque
383 lb-ft
Economy
15 city city
Owners
2
Days on lot
34
DEFECT LOG
4 findings, published
1 MODERATE
Everything the protocol found, including what we decided not to repair. Each finding says what it is and what we did about it — nothing here is hidden behind “sold as seen”.
| Severity | Finding | Action taken |
|---|---|---|
| MODERATE | AFM lifter tick on cold start, cylinder 6 | Disclosed, not repaired — priced in |
| MINOR | Driver seat bolster wear | Left as is |
| MINOR | Rear wheel arch stone chips | Touched in |
| NOTE | Transmission fluid dark at 96k | Serviced by us |
Model watch list
What this generation is known for.
Every model has faults that show up again and again in the workshop and in the manufacturer’s own bulletins. These are the ones documented for this exact year, engine and transmission — listed whether or not this particular car shows them.
- AFM lifter collapse on the 5.3 L L83 — misfire and camshaft damage
- 8L90 / 6L80 torque converter shudder and harsh shifts — GM TSBs
- Transmission thermal bypass valve failure — GM TSB 21-NA-199
- Direct-injection intake valve carbon build-up causing rough idle
Notes on the data
- GM’s LTZ fast-facts sheet lists the 8-speed as the LTZ transmission; a 6-speed build is rated 16/22/18 instead of 15/21/17.
- Towing and payload are the Max Trailering build; without that package payload is 1,730 lb.
- 0–60 mph is an exact-configuration test (2016 Z71 Crew Cab 4x4, 5.3 L, 8-speed).
Specifications verified against
BUILD SHEET
Specification
3GCUKSEC•••••771
- Stock number
- TA-1044
- Body
- Truck
- Engine
- 5.3L V8
- Power
- 355 hp @ 5,600 rpm
- Torque
- 383 lb-ft @ 4,100 rpm
- Transmission
- 8-speed automatic
- Drivetrain
- 4WD
- 0–60 mph
- 6.9 s
- Curb weight
- 5,440 lb
- Seating
- 5
- Dimensions
- 230 in long · 80 wide · 74 high · 143.5 in wheelbase
- Cargo
- 53.4 cu ft (bed volume)
- Towing, max
- 10,800 lb
- Payload, max
- 2,130 lb
- Fuel tank
- 26 US gal
- EPA economy
- 15 city / 21 hwy / 17 combined mpg
- NHTSA overall
- 5 of 5 stars
- Fuel
- Gasoline
- Economy
- 15 city / 21 highway
- Odometer
- 96,150 mi
- Exterior
- Victory Red
- Interior
- Jet black leather
- VIN (masked)
- 3GCUKSEC•••••771
- Title
- Clean · Georgia, in hand
- Previous owners
- 2
- Days on lot
- 34
HIGHLIGHTS
- Z71 package with skid plates
- Priced $2,000 under the market band because of disclosed lifter tick
- Fresh transmission service
PAPER FILE
Service history
2 RECORDS
- 96,150 mi Our intake: transmission service, compression, alignment In-house bay
- 91,200 mi Oil service, front brake pads Independent shop
INSPECTOR NOTES
- This is the honest-broker unit on the lot: the 5.3 AFM lifter issue is real, we measured it, and the price reflects a repair you may never need.
- If you want it corrected in our bay before delivery, we quote it at cost plus labour.
HANDOVER
What leaves with the car
4 ITEMS
-
DOC-01
The inspection sheet
All 120 points with the measured values, photographs and the defect log — printed and emailed.
-
DOC-02
The paper file
Title, service records, prior invoices, recall status and the purchase order in one folder.
-
DOC-03
The measurement log
Compression, alignment, battery and paint depth readings, kept as a spreadsheet you can hand to your own mechanic.
-
DOC-04
The 30-day window
Powertrain coverage for thirty days, stated on the purchase order, honoured in our own bay.
